Appendix 107
Connectors
External connectors:
Video
15-hole connector
Network adapter
RJ-45 connector
USB
two front-panel and five back-panel USB 2.0-compliant connectors
Audio
five connectors for line-in, line-out, microphone/ side-surround,
surround, and center/subwoofer connector (LFE channel);
two
front-panel connectors for headphones and microphone
System board connectors:
Primary IDE drive
one 40-pin connector on PCI local bus
Serial ATA
two 7-pin connectors
FlexBay Drive
one USB 10-pin header for optional Media Card Reader (3.5-inch
bay device)
Floppy drive
one 33-pin connector
Fan
one 5-pin connectors
PCI 2.3
two 120-pin connectors
PCI Express x1
one 36-pin connector
PCI Express x16
one 164-pin connector
Controls and Lights
Power button push button
Power light green light — Blinking green in sleep state; solid green for power-
on state.
amber light — Blinking amber indicates a problem with the power
supply inside the computer. If the system cannot boot and there is
a solid amber light, this indicates a problem with the system board
(see "Power Problems" on page 40).
Hard-drive access light green
Link integrity light (on integrated
network adapter)
green light — A good connection exists between a 10-Mbps
network and the computer.
orange light — A good connection exists between a 100-Mbps
network and the computer.
off (no light) — The computer is not detecting a physical
connection to the network.
Activity light (on integrated network
adapter)
yellow blinking light
