Removing and Installing Parts 87
3
Press in on the blue tabs on each side of the drive and slide the drive up and out of the computer.
Installing a Hard Drive
1
Unpack the replacement hard drive, and prepare it for installation.
2
Check the documentation for the drive to verify that it is configured for your computer.
NOTE: If your replacement hard drive does not have the hard drive bracket attached, remove the bracket from the
old drive by unsnapping it from the drive. Snap the bracket onto the new drive.
serial ATA
data cable
power cable
tabs (2)
hard drive
