94 Removing and Installing Parts
Media Card Reader
For information on using the Media Card Reader, see "Using a Media Card Reader (Optional)" on
page 20.
Removing a Media Card Reader
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions located in the
Product Information Guide.
NOTICE: To prevent static damage to components inside your computer, discharge static electricity from your
body before you touch any of your computer’s electronic components. You can do so by touching an unpainted
metal surface on the computer chassis.
1
Follow the procedures in "Before You Begin" on page 59.
2
Lay the computer on its side so that the system board is on the bottom of the inside of the computer.
3
Remove the computer cover (see "Removing the Computer Cover" on page 65).
4
Remove the drive panel (see "Removing the Drive Panel" on page 81).
cable
*Media Card Reader
*
Not present on all computers.
