108 Appendix
Diagnostic lights four lights on the front panel (see "Diagnostic Lights" on page 47.)
Standby power light AUX_PWR on the system board
Power
DC power supply:
Wattage
305 W
Heat dissipation
560.5 BTU/hr
Voltage (see the safety instructions
located in the
Product Information
Guide
for important voltage setting
information)
90 to 135 V and 180 to 265 V at 50/60 Hz
Backup battery 3-V CR2032 lithium coin cell
Physical
Height 41.4 cm (16.3 inches)
Width 18.8 cm (7.4 inches)
Depth 45.7 cm (18.0 inches)
Weight 12.7 kg (28 lb)
Environmental
Temperature:
Operating
10° to 35°C (50° to 95°F)
NOTE: At 35°C (95°F), the maximum operating altitude is 914 m
(3000 ft).
Storage
–40° to 65°C (–40° to 149°F)
Relative humidity 20% to 80% (noncondensing)
Maximum vibration:
Operating
0.25 G at 3 to 200 Hz at 0.5 octave/min
Storage
0.5 G at 3 to 200 Hz at 1 octave/min
Maximum shock:
Operating
bottom half-sine pulse with a change in velocity of 20 inches/sec
(50.8 cm/sec)
Storage
27-G faired square wave with a velocity change of 200 inches/sec
(508 cm/sec)
Controls and Lights (continued)
