Removing and Replacing Parts 4-21
([SDQVLRQ&DUGV
)LJXUH ([SDQVLRQ &DUG 5HPRYDO
To remove an expansion card, follow these steps:
1. Disconnect any cables from the expansion card.
Note the location of each connector and the orientation of any cables
attached to the expansion card before disconnecting these cables.
2. Remove the retaining screw from the card-mounting bracket (see
Figure 4-19).
3. Grasp the expansion card by its corners, and carefully pull it out of its
expansion-card connector.
