Dell E2010H - Resolution Specifications; Electrical Specifications; Preset Display Modes; Physical Characteristics

Resolution Specifications
Electrical Specifications
Model number
Dell E2010H/E2210H/E2310H Flat Panel
Monitor
Scan range
l Horizontal
l Vertical

30 kHz to 83 kHz (automatic)
50 Hz to 75 Hz (automatic)
Maximum preset resolution
1600 x 900 at 60 Hz (For E2010H)
1920 x 1080 at 60 Hz (For E2210H/E2310H)
Model number
Dell E2010H/E2210H/E2310H Flat Panel
Monitor
Video input signals
Analog RGB: 0.7 Volts +/-5%, 75 ohm input
impedance
Synchronization input signals
Separate horizontal and vertical
synchronizations, polarity-free TTL level.
AC input voltage / frequency / current
100 to 240 VAC/50 or 60 Hz + 3 Hz/1.6A (Max.)
Inrush current
120V:30A (Max.)
240V:60A (Max.)
Preset Display Modes
The following table lists the preset modes for which Dell guarantees image size and centering:
Display Mode
Horizontal Frequency
(kHz)
Vertical Frequency
(Hz)
Pixel Clock (MHz)
Sync Polarity
(Horizontal/Vertical)
VESA, 720 x 400
31.5
70.0
28.3
-/+
VESA, 640 x 480
31.5
60.0
25.2
-/-
VESA, 640 x 480
37.5
75.0
31.5
-/-
VESA, 800 x 600
37.9
60.0
40.0
+/+
VESA, 800 x 600
46.9
75.0
49.5
+/+
VESA, 1024 x 768
48.4
60.0
65.0
-/-
VESA, 1024 x 768
60.0
75.0
78.8
+/+
VESA, 1152 x 864
67.5
75.0
108.0
+/+
VESA, 1280 x 1024
(For E2210H/E2310H)
64.0
60.0
108.0
+/+
VESA, 1280 x 1024
(For E2210H/E2310H)
80.0
75.0
135.0
+/+
VESA, 1600 x 900
(For E2010H)
55.5
60.0
97.8
+/-
VESA, 1920 x 1080
(For E2210H/E2310H)
67.5
60.0
148.5
+/+
Physical Characteristics
The following table lists the monitor physical characteristics:
Model Number
Dell E2010H Flat Panel Monitor
Dell E2210H Flat Panel Monitor
Dell E2310H Flat Panel Monitor
Connector type
15-pin D-subminiature, blue connector; DVI-D,
white connector
15-pin D-subminiature, blue connector;DVI-D,
white connector
15-pin D-
subminiature, blue connector; DVI
white connector
Signal cable type
Analog: Detachable, D-Sub, 15pins, shipped
attached to the monitor
Digital: Detachable, DVI-D, Solid pins, shipped
detached from the monitor
Analog: Detachable, D-Sub, 15pins, shipped
attached to the monitor
Digital: Detachable, DVI-D, Solid pins, shipped
detached from the monitor
Analog:
Detachable, D
attached to the monitor
Digital: Detachable, DVI
detached from the monitor
Dimensions: (with stand)
l Height
l Width

363.2 mm (14.30 inches)
481.2 mm (18.94 inches)

381.0 mm (15.00 inches)
515.0 mm (20.28 inches)

401.8 mm (15.82 inches)
548.8 mm (21.61 inches)
