About Your Monitor 11
Electrical Specifications
Model number
E2218HN
Video input signals • Analog RGB: 0.7 Volts ± 5 %, 75 ohm input impedance
• HDMI , 600 mV for each differential line, 100 ohm input
impedance per differential pair
Synchronization input
signals
Separate horizontal and vertical synchronizations, polarity-free
TTL level, SOG (Composite SYNC on green)
AC input voltage /
frequency / current
100 VAC to 240 VAC / 50 Hz or 60 Hz ± 3 Hz / 1.0 A (typical)
Inrush current 120 V: 30 A (Max.)
240 V: 50 A (Max.)
Physical Characteristics
The following table lists the monitor’s physical characteristics:
Model Number E2218HN
Signal cable type • Analog: D-Sub, 15 pins
• Digital: HDMI, 19 pins
Dimensions: (with stand)
Height
Width
Depth
396.7 mm (15.62 in.)
512.2 mm (20.17 in.)
180.0 mm (7.09 in.)
Dimensions: (without stand)
Height
Width
Depth
303.7 mm (11.96 in.)
512.2 mm (20.17 in.)
50.5 mm (1.99 in.)
Stand dimensions:
Height
Width
Depth
177.0 mm (6.97 in.)
250.0 mm (9.84 in.)
180.0 mm (7.09 in.)
Weight:
Weight with packaging 4.85 kg (10.69 lb)
Weight with stand assembly and cables 3.63 kg (8.0 lb)
Weight without stand assembly (For wall mount or
VESA mount considerations - no cables)
2.84 kg (6.26 lb)
Weight of stand assembly 0.52 kg (1.15 lb)
