Operating your monitor 23
Operating your monitor
Turning on the monitor
Press the button to turn on the monitor.
Using the front panel controls
Use the control buttons at the bottom edge of the monitor to adjust the image being displayed.
1
2
3
4
5
The following table describes the control buttons:
Control buttons Description
1
Preset mode
Use this button to choose from a list of preset modes.
2
Brightness/Contrast
For direct access to the Brightness and Contrast menu.
3
Menu
To launch the On-Screen Display (OSD) menu, or to
access the list of items/options of a menu item. For
more information, see Accessing the OSD menu.
4
Exit
To exit or return to the OSD main menu.
5
Power button
(with power-status light)
To turn the monitor On or Off.
Solid white light indicates that the monitor is turned on
and functioning normally. Blinking white light indicates
that the monitor is in Standby Mode.

Other manuals for Dell E2223HN

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell E2223HN and is the answer not in the manual?

Dell E2223HN Specifications

General IconGeneral
Panel typeVA
Color gamut83 %
Pixel pitch0.249 x 0.241 mm
Screen shapeFlat
Pixel density103 ppi
Response time10 ms
Backlight typeLED
Display diagonal21.45 \
Anti-glare screenYes
Display technologyLCD
Native aspect ratio16:9
Vertical scan range50 - 75 Hz
Maximum refresh rate60 Hz
Response time (fast)5 ms
Viewable size diagonal544.83 mm
Viewable size, vertical260.28 mm
Contrast ratio (typical)3000:1
Display number of colors16.7 million colors
Display diagonal (metric)54.48 cm
Viewable size, horizontal478.66 mm
Display brightness (typical)250 cd/m²
Tilt angle range-5 - 21 °
Cable lock slot typeKensington
Panel mounting interface100 x 100 mm
Doesn't containPVC/BFR
Sustainability certificatesENERGY STAR, RoHS, TCO
HDMI version1.4
DisplayPorts quantity0
Input current0.7 A
AC input voltage100 - 240 V
Power supply typeInternal
AC input frequency50 - 60 Hz
Power consumption (max)19 W
Power consumption (standby)0.3 W
Power consumption (typical)12.83 W
Package depth355 mm
Package width565.9 mm
Package height119.8 mm
Package weight4140 g
Operating altitude0 - 5000 m
Non-operating altitude5000 - 12192 m
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 80 %
RMS rated power0 W
Product colorBlack
Heavy metals freeHg (mercury)
Market positioningOffice
Harmonized System (HS) code85285210
Weight and Dimensions IconWeight and Dimensions
Bezel width (top)12.8 mm
Depth (with stand)171 mm
Width (with stand)504.26 mm
Height (with stand)384.17 mm
Weight (with stand)2590 g
Bezel width (bottom)16.9 mm
Depth (without stand)49.64 mm
Height (without stand)295.38 mm
Weight (without stand)2260 g
