26 | Operating the Monitor
2 Pr
ess the and buttons to move between the setting options. As you move
from one icon to another, the option name is highlighted. See
the following table
for a complete list of all the options available for the monitor.
3 Pr
ess the button once to activate the highlighted option.
4 Pr
ess the and buttons to select the desired parameter.
5 Press to enter the slide bar and then use the and buttons, according to
the indicators on the menu, to make your changes.
6 Select the button to return to the main menu.
The table below provides a list of all the OSD menu options and their functions.
Icon Menu and
Submenus
Description
Brightness/
Contrast
Use this menu to activate Brightness/Contrast adjustment.
Brightness
Brightness adjusts the luminance of the backlight.
Press the
button to increase the brightness and press the
button to decrease the brightness (min. 0 / max. 100).
Contrast
Adjust the Brightness first, and then adjust the Contrast only if further
adjustment is necessary.
Press the
button to increase the contrast and press the
button to decrease the contrast (min. 0 / max. 100).
The Co
ntrast function adjusts the degree of difference between
darkness and lightness on the monitor screen.
