Dell E2423H - Page 10

10 │ About your monitor
Monitor specifications
Model E2423H/E2423HN
Screen type Active matrix-TFT LCD
Panel type Vertical Alignment (VA)
Viewable area
Diagonal 604.70 mm (23.8 in.)
Active area
Horizontal
Vertical
Area
527.04 mm (20.75 in.)
296.46 mm (11.67 in.)
1562.46 cm
2
(242.18 in.
2
)
Pixel pitch 0.2745 mm x 0.2745 mm
Pixel per inch (PPI) 93
Viewing angle
Horizontal
Vertical
178° (typical)
178° (typical)
Brightness 250 cd/m² (typical)
Contrast ratio 3,000 to 1 (typical)
Faceplate coating Anti-glare with 3H hardness
Backlight LED edgelight system
Response time
Normal mode
Fast mode
< 8 ms
< 5 ms
Color depth 16.7 million colors
Color gamut 72% NTSC (CIE1931)
83% NTSC (CIE1976)
Dell display manager
compatibility
Yes
Connectivity E2423H: 1 x DP1.2, 1 x VGA
E2423HN: 1 x HDMI 1.4, 1 x VGA
Bezel width (edge of
monitor to active area)
12.8 mm (Top)
12.8 mm (Left/Right)
22.35 mm (Bottom)
Security Security-lock slot for cable lock (optional purchase)
Tilt angle -5° to 21°
