Dell E2722HS - Disassembly Steps

13
5.1Disassembly Procedures
Step
Figure
TOOl
Remark
Remove the
Base ass’y.
Unscrew the screw
loosely by hand and
pull out the stand.
Note:
Put the monitor on a
flat, soft and clean
surface.
.
Unscrew the 4 screws
by the Philips-head
Screwdriver and insert
the scraper into the
button site to open the
rear cover
Remove the
Rear cover
Disconnect speaker
cables
