NOTE: In Config11, R1 and R4 paddle cards do not have a physical PCIe slot. see R1 and R4 paddle card installation.
Table 134. Configuration 0: No risers
Card type Slot priority Maximum number of cards
Inventec (LOM Card) Integrated slot 1
Intel (OCP: 25Gb) Integrated slot 1
Broadcom (OCP: 25Gb) Integrated slot 1
Intel (OCP: 25Gb) Integrated slot 1
Broadcom (OCP: 25Gb) Integrated slot 1
Broadcom (OCP: 10Gb) Integrated slot 1
Intel (OCP: 10Gb) Integrated slot 1
Intel (OCP: 10Gb) Integrated slot 1
Broadcom (OCP: 1Gb) Integrated slot 1
Intel (OCP: 1Gb) Integrated slot 1
Foxconn (BOSS) Integrated slot 1
Foxconn (Front PERC12) Integrated slot 2
Foxconn (Front PERC11) Integrated slot 2
Foxconn (Front PERC11) Integrated slot 2
Foxconn (Front PERC11) Integrated slot 1
Foxconn (Front PERC11) Integrated slot 1
Foxconn (Front PERC11) Integrated slot 1
Foxconn (Front PERC11) Integrated slot 1
Table 135. Configuration 1: R1B+R2A+R3B+R4B
Card type Slot priority Maximum number of cards
Inventec (VGA) 8, 4 1
Inventec (Serial) 8, 4 1
Mellanox (DPU: 25Gb) 5, 4, 7, 1, 2 5
Inventec (LOM Card) Integrated slot 1
Intel (OCP: 25Gb) Integrated slot 1
Broadcom (OCP: 25Gb) Integrated slot 1
Intel (OCP: 25Gb) Integrated slot 1
Broadcom (OCP: 25Gb) Integrated slot 1
Broadcom (OCP: 10Gb) Integrated slot 1
Intel (OCP: 10Gb) Integrated slot 1
Intel (OCP: 10Gb) Integrated slot 1
Broadcom (OCP: 1Gb) Integrated slot 1
Intel (OCP: 1Gb) Integrated slot 1
Foxconn (BOSS) Integrated slot 1
Foxconn (Front PERC12) Integrated slot 2
210 Installing and removing system components
