Table 135. Configuration 1: R1B+R2A+R3B+R4B (continued)
Card type Slot priority Maximum number of cards
Broadcom (NIC: 10Gb) 6, 3 2
Broadcom (NIC: 10Gb) 5, 4, 7, 1, 6, 3, 2 7
Broadcom (NIC: 10Gb) 5, 4, 7, 1, 2 5
Broadcom (NIC: 10Gb) 6, 3 2
Intel (NIC: 10Gb) 5, 4, 7, 1, 2 5
Intel (NIC: 10Gb) 6, 3 2
Intel (NIC: 10Gb) 5, 4, 7, 1, 2 5
Intel (NIC: 10Gb) 6, 3 2
Intel (NIC: 1Gb) 5, 4, 7, 1, 2 5
Intel (NIC: 1Gb) 6, 3 2
Intel (NIC: 1Gb) 5, 4, 7, 1, 2 5
Intel (NIC: 1Gb) 6, 3 2
Broadcom (NIC: 1Gb) 5, 4, 7, 1, 2 5
Broadcom (NIC: 1Gb) 6, 3 2
Foxconn (External Adapter) 5, 4, 7, 1, 6, 3, 2 7
Table 136. Configuration 2: R1Q+R2A+R3B+R4Q
Card type Slot priority Maximum number of cards
Inventec (VGA) 8, 4 1
Inventec (Serial) 8, 4 1
Mellanox (DPU: 25Gb) 5, 4, 7, 1, 2 5
Inventec (LOM Card) Integrated slot 1
Intel (OCP: 25Gb) Integrated slot 1
Broadcom (OCP: 25Gb) Integrated slot 1
Intel (OCP: 25Gb) Integrated slot 1
Broadcom (OCP: 25Gb) Integrated slot 1
Broadcom (OCP: 10Gb) Integrated slot 1
Intel (OCP: 10Gb) Integrated slot 1
Intel (OCP: 10Gb) Integrated slot 1
Broadcom (OCP: 1Gb) Integrated slot 1
Intel (OCP: 1Gb) Integrated slot 1
Foxconn (BOSS) Integrated slot 1
Foxconn (Front PERC12) Integrated slot 2
Foxconn (Front PERC11) Integrated slot 2
Foxconn (Front PERC11) Integrated slot 2
Foxconn (Front PERC11) Integrated slot 1
Foxconn (Front PERC11) Integrated slot 1
Foxconn (Front PERC11) Integrated slot 1
212 Installing and removing system components
