Dell EMC Edge Gateway 5200 Service Manual

Installation procedure for 2x GbE LAN uFM
module
About this task
Installation requires the removal of WiFi, as well as COM3 and COM4 ports. The 4-port COM cable will be replaced with an
included dual-port COM cable.
Table 9. Expansion module packing list
Item Quantity Notes
Screw M3 x 6L 2 Torque required: 4.0 kgf.cm
Screw M3 x 4L 14 Torque required: 4.0 kgf.cm
Screw M3 x 5L 1 Torque required: 4.0 kgf.cm
Standoff H4 4 Torque required: 4.5 kgf.cm
Nut M3 4 Torque required: 4.0 kgf.cm
Screw M2.5 x 6L 2 Torque required: 3.0 kgf.cm
Cable tie 2 -
Rubber cap 2 -
Cable clip 1 -
Sheet metal I/O panel 1 -
Bracket 1 -
LAN PCBA 1 -
LAN mPCIe 1 -
Dual-port COM cable 1 -
LAN cable 2 -
Steps
1. Remove the eight screws from the bottom panel of the EGW-5200, as shown in the following figure, and remove the bottom
panel.
V
38 Installation procedure for 2x GbE LAN uFM module
