PS6610 Hardware Owner's Manual 1 Basic Storage Array Information
Figure 1: Front Panel Features
Table 1: Front Panel Feature Identification
Item Description
1 Recessed Handle
2 Anti-Tamper Lock
3 Sideplane Status Indicator
4 Enclosure Status Indicator
Figure 2: Anti-Tamper Locks
Note: The anti-tamper locks require a T20 Torx key (included). To lock drawers, turn the key until
the red arrows point away from the center of the enclosure.
2
