10 | About your monitor
Back view
7
1
2
3
4
5
6
Label Description Use
1 VESA mounting holes (100 mm x
100 mm-behind attached VESA
cover)
Wall mount monitor using VESA-
compatible wall mount kit (100 mm x 100
mm).
2 Regulatory label Lists the regulatory approvals.
3 Stand release button Releases stand from the monitor.
4 Joystick Use it to control the OSD menu.
5 Function buttons For more information, see Operating the
monitor.
6 Barcode, serial number, and Service
Tag label
Refer to this label if you need to contact
Dell for technical support. The Service
Tag is a unique alphanumeric identifier
that enables Dell service technicians
to identify the hardware components
in your computer and access warranty
information.
7 Cable-management slot Use to organize cables by inserting them
through the slot.
