About your monitor | 11
Bottom view
1 2 4 5 63 7
Label Description Use
1 Power connector Connect the power cable (shipped with your monitor).
2 Security lock slot Secures monitor with security cable lock (sold separately).
3 Stand lock Lock the stand to the monitor using a M3 x 6 mm screw
(screw not included).
4 HDMI port
(HDMI 1)
Connect your computer with the HDMI cable (shipped with
your monitor).
5 HDMI port
(HDMI 2)
Connect your computer with the HDMI cable (shipped with
your monitor).
6 DisplayPort Connect to your computer with the DisplayPort cable
(shipped with your monitor).
7 Headphone port Connect the headphones to the monitor.
WARNING: The possible long-term effect of
listening to audio at high volume through the
headphones may cause damage to your hearing
ability.
