Replacing the power-button
board
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Align the screw holes on the power-button board with the screw holes on the
palm rest and keyboard assembly.
2 Replace the two screws (M2x2.5) that secure the power-button board to the
palm rest and keyboard assembly.
Post-requisites
1 Follow the procedure from step 3 to step 9 in “Replacing the palm rest and
keyboard assembly”.
2 Replace the rear cover.
3 Replace the battery.
4 Replace the base cover.
65
