Replacing the display assembly
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Align the screw holes on the display assembly with the screw holes on the
computer base.
2 Replace the two screws (M2x2.5) that secure the display assembly to the
computer base.
3 Close the display and turn the computer over.
4 Replace the two screws (M2x3) that secure the display assembly to the
computer base.
5 Replace the two screws (M2.5x5) that secure the display assembly to the
computer base.
6 Route the display cable through the routing guides on the computer base.
7 Adhere the display cable and the camera cable to the computer base.
8 Connect the display cable to the system board.
9 Align the screw hole on display-cable bracket with the screw hole on the
computer base.
10 Replace the screw (M3x3) that secures the display-cable bracket to the
computer base.
11 Route the antenna cables through the routing guides on the computer base.
12 Adhere the camera cable to the computer base.
13 Connect the camera cable to the system board.
Post-requisites
1 Follow the procedure from step 3 to step 9 in “Replacing the palm rest and
keyboard assembly”.
2 Replace the wireless card.
