Adding and Replacing Parts 125
Hinge Cover
Removing the Hinge Cover
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions in the Product
Information Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically
touching an unpainted metal surface (such as a connector on the back of the computer).
NOTICE: To avoid damaging the system board, you must remove the main battery before you begin working inside
the computer.
NOTICE: The hinge cover is fragile and can be damaged if extreme force is used. Be careful when removing the
hinge cover.
1
Follow the procedures in "Before You Begin" on page 109.
2
Remove the battery (see "Replacing the Battery" on page 41).
3
Remove the two screws inside the battery bay.
1 antenna cables (2)
1
