Dell Inspiron 7590 2in1 User Manual

Removing the wireless card
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
Remove the base cover.
Procedure
1. Locate the wireless card on the system board.
2. Remove the screw (M2x3) that secures the wireless-card bracket to the wireless card and palm-rest assembly.
3. Remove the wireless-card bracket from the wireless card.
4. Disconnect the antenna cables from the wireless card.
5. Slide and remove the wireless card from the wireless-card slot.
12
Removing the wireless card 29

Dell Inspiron 7590 2in1 Specifications

General

Display Size	15.6 inches
Operating System	Windows 10 Home
Webcam	720p HD
Audio	Stereo speakers with Waves MaxxAudio Pro
Model	Dell Inspiron 7590 2-in-1
Display Type	IPS
Processor	Intel Core i5 / i7
RAM	16GB DDR4
Storage	512GB SSD
Graphics	Intel UHD Graphics
Ports	HDMI, SD card reader, headphone/microphone combo
Wireless	802.11ac Wi-Fi, Bluetooth
