Dell Inspiron 7590 2in1 User Manual

Replacing the touchpad
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1. Slide the touchpad into the slot on the palm-rest assembly.
2. Replace the two screws (M1.6x2) that secure the touchpad to the palm-rest assembly.
3. Align the screw holes on the touchpad bracket with the screw holes on the palm-rest assembly.
4. Replace the three screws (M2x3) that secure the touchpad bracket to the palm-rest assembly.
5. Adhere the tape that secures the touchpad bracket to the palm-rest assembly.
6. Adhere the tapes that secure the touch-pad assembly to the palm-rest assembly.
7. Slide the touchpad cable into the connector on the system board and close the latches to secure the cable.
27
Replacing the touchpad 57

Dell Inspiron 7590 2in1 Specifications

General

Display Size	15.6 inches
Operating System	Windows 10 Home
Webcam	720p HD
Audio	Stereo speakers with Waves MaxxAudio Pro
Model	Dell Inspiron 7590 2-in-1
Display Type	IPS
Processor	Intel Core i5 / i7
RAM	16GB DDR4
Storage	512GB SSD
Graphics	Intel UHD Graphics
Ports	HDMI, SD card reader, headphone/microphone combo
Wireless	802.11ac Wi-Fi, Bluetooth
