Removing the display assembly
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
1. Remove the base cover.
2. Remove the fan.
Procedure
1. Open the latch and disconnect the touchscreen-board cable from the system board.
2. Peel the tape to release the touchscreen-board cable and remove the cable from the routing guides on the palm-rest
assembly.
3. Using the pull tab, disconnect the display cable from the system board.
4. Peel the tape that secures the display cable to the system board.
5. Turn the computer over and open the display as far as possible.
CAUTION: Place the computer on a soft and clean surface to avoid scratching the display.
32
Removing the display assembly 63

Dell Inspiron 7590 2in1 Specifications

General

Display Size	15.6 inches
Operating System	Windows 10 Home
Webcam	720p HD
Audio	Stereo speakers with Waves MaxxAudio Pro
Model	Dell Inspiron 7590 2-in-1
Display Type	IPS
Processor	Intel Core i5 / i7
RAM	16GB DDR4
Storage	512GB SSD
Graphics	Intel UHD Graphics
Ports	HDMI, SD card reader, headphone/microphone combo
Wireless	802.11ac Wi-Fi, Bluetooth
