3. Replace the fan (see Replacing the Fan).
4. Replace the bottom of the base assembly (see Removing the Bottom of the Base Assembly).
5. Replace the battery (see Replacing the Battery).
Integrated Graphics Thermal-Cooling Assembly
1. Place the vent-end of the thermal-cooling assembly into the computer at an angle, then align the four captive screws on the thermal-cooling assembly
with the screw holes on the system board.
2. In sequential order, tighten the four captive screws to secure the thermal- cooling assembly to the system board.
3. Replace the fan (see Replacing the Fan).
4. Replace the bottom of the base assembly (see Removing the Bottom of the Base Assembly).
5. Replace the battery (see Replacing the Battery).
