Replacing an FCM




1. Slide the FCM card into the connector.

2. Press the card down to the alignment post and hold in position.

3. Replace the screw in the FCM card.

4. Replace the left hinge cover (see Replacing the Hinge Covers).

5. Replace the bottom of the base assembly (see Removing the Bottom of the Base Assembly).

6. Replace the battery (see Replacing the Battery).
Back to Contents Page

CAUTION: The connectors are keyed to ensure correct insertion. If you feel resistance, check the connectors on the card and on the system
board, and realign the card.
CAUTION: To avoid damage to the FCM card, ensure the cables are not under the card when you replace the card.
CAUTION: The Mini-Card slot has WPAN/UWB/FCM silk-screened inside the slot. Do not install FCM cards in any other Mini-Card slot.
