Dell Latitude 5285 2-in-1 User Manual

Feature Specication
Diagonal 312.42 mm (12.0 inches)
Maximum resolution 1920x1280
Refresh rate 60 Hz
Maximum viewing
angles—horizontal
+/-80°
Maximum viewing
angles—vertical
+/-80°
Pixel pitch
0.135 mm
AC adapter
specications
Feature Specication
Type 45 W USB Type-C and 65 W USB Type-C
Input voltage 100 V AC to 240 V AC
Input current—
maximum
1.3 A / 1.7 A
Input frequency 47 Hz to 63 Hz
Output current 2.25 A, 3 A, and 3.25 A
Rated output
voltage
20 VDC/15 VDC/9 VDC/5 VDC
Weight
• 0.385 lbs(45 W) and 0.476 lbs(65 W)
• 175 g (45 W) and 216.2 g (65 W)
Dimensions
• 0.191 x 0.121 x 0.048 inches (45 W) and 0.217 x 0.145 x 0.048 (65 W)
• 87 x 55 x 22 mm (45 W) and 99 x 66 x 22 mm (65 W)
Temperature range
—Operating
0°C to 40°C (32°F to 104°F)
Temperature range
—Non-Operating
–40°C to 70°C (–40°F to 158°F)
Battery specications
Feature
Specication
Type
• 32Whr Polymer battery with ExpressCharge
• 42Whr Polymer battery with ExpressCharge
• 42WHr Polymer Long Life Cycle
32Whr :
Length 177.6 mm (6.99 inches)
8 Technical specications

Dell Latitude 5285 2-in-1 Specifications

General

Graphics	Intel HD Graphics 620
Operating System	Windows 10 Pro
Bluetooth	Bluetooth 4.2
Processor	Intel Core i7-7600U
Display	12.3" FHD (1920x1280) Touchscreen
Memory	Up to 16GB DDR4
Storage	Up to 1TB PCIe SSD
Battery	42 WHr integrated battery
Ports	1 x microSD card reader, 1 x headphone/microphone combo jack
Wireless	Intel Dual Band Wireless-AC 8265
Webcam	8MP camera
