Chassis
This chapter illustrates the multiple chassis views along with the ports and connectors and also explains the FN hot key combinations.
Topics:
• Front view
• Left view
• Right view
• Top view
• Bottom view
• Chassis modes
Front view
1 Proximity sensor receiver
2 Proximity sensor emitter
3 IR emitter
