Dell Latitude D630 User Manual

Adding and Replacing Parts 109
Adding and Replacing Parts
Before You Begin
This chapter provides procedures for removing and installing the components in your computer.
Unless otherwise noted, each procedure assumes that the following conditions exist:
• You have performed the steps in "Turning Off Your Computer" on page 109 and "Before Working
Inside Your Computer" on page 109.
• You have read the safety information in your Dell™
Product Information Guide.
• A component can be replaced or—if purchased separately—installed by performing the removal
procedure in reverse order.
Recommended Tools
The procedures in this document may require the following tools:
• Small flat-blade screwdriver
• Small Phillips screwdriver
• Small plastic scribe
• Flash BIOS update program CD
Turning Off Your Computer
NOTICE: To avoid losing data, save and close any open files and exit any open programs before you turn off
your computer.
1 Shut down the operating system:
a Save and close any open files, exit any open programs, click Start → Shut Down → Shut
down
→ ΟΚ.
The computer turns off after the operating system shutdown process finishes.
2 Ensure that the computer and any attached devices are turned off. If your computer and attached
devices did not automatically turn off when you shut down your operating system, press and hold
the power button for 4 seconds.
Before Working Inside Your Computer
Use the following safety guidelines to help protect your computer from potential damage and to
help ensure your own personal safety.

Dell Latitude D630 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black, Grey
Memory slots	2x SO-DIMM
Internal memory	2 GB
Memory clock speed	667 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
3D	No
AC adapter included	Yes
Disc types supported	CD, DVD
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	-
Total storage capacity	80 GB
Number of HDDs installed	1
Pixel pitch	0.2373 x 0.2373 mm
Display diagonal	14.1 \
Display brightness	220 cd/m²
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Maximum on-board graphics card memory	- GB
On-board graphics card dynamic frequency (max)	- MHz
Speaker power	2 W
Wi-Fi standards	802.11a, 802.11b, 802.11g
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Pointing device	Touchpad
Operating system installed	Windows 7 Home Premium
Operating system architecture	64-bit
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Operating shock	143 G
Operating altitude	-15.2 - 3048 m
Non-operating shock	163 G
Operating vibration	0.66 G
Non-operating altitude	-15.2 - 10668 m
Non-operating vibration	1.3 G
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	ENERGY STAR
Tcase	- °C
Bus type	FSB
Stepping	M0
Tjunction	100 °C
Processor cache	2 MB
Processor cores	2
Processor model	T7250
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo T7000 Series
Processor socket	Socket 478
Processor codename	Merom
Processing Die size	143 mm²
Processor frequency	2 GHz
Processor cache type	L2
Configurable TDP-down	- W
Processor lithography	65 nm
Processor manufacturer	Intel
Processor front side bus	800 MHz
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	10
Number of Processing Die Transistors	291 M
Processor code	SLA49
Processor ARK ID	31728
Processor package size	35 x 35 mm
Graphics & IMC lithography	- nm

Weight and Dimensions

Depth	238 mm
Width	337 mm
Height	32.3 mm
Weight	2270 g
