Dell Latitude E7440 Series User Manual

Quick Setup
WARNING: Before you begin any of the procedures in this section, read the safety information that shipped with
your computer. For additional best practices information, see www.dell.com/regulatory_compliance
WARNING: The AC adapter works with electrical outlets worldwide. However, power connectors and power
strips vary among countries. Using an incompatible cable or improperly connecting the cable to the power strip or
electrical outlet may cause fire or equipment damage.
CAUTION: When you disconnect the AC adapter cable from the computer, grasp the connector, not the cable
itself, and pull firmly but gently to avoid damaging the cable. When you wrap the AC adapter cable, ensure that
you follow the angle of the connector on the AC adapter to avoid damaging the cable.
NOTE: Some devices may not be included if you did not order them.
1. Connect the AC adapter to the AC adapter connector on the computer and to the electrical outlet.
Figure 7. AC Adapter
2. Connect the network cable (optional).
Figure 8. Network Connector
3. Connect USB devices, such as a mouse or keyboard (optional).
Figure 9. USB Connector
4. Open the computer display and press the power button to turn on the computer.
6

Dell Latitude E7440 Series Specifications

General

Graphics	Intel HD Graphics 4400
Wireless	Intel Dual Band Wireless-AC 7260, Bluetooth 4.0
Processor	Intel Core i5-4300U / i7-4600U
Display	14-inch HD (1366x768) or FHD (1920x1080) anti-glare
RAM	4GB / 8GB DDR3L
Storage	128GB/256GB/512GB SSD
Operating System	Windows 7 Professional / Windows 8.1 Pro
Weight	Starting at 1.63 kg (3.6 lbs)
Battery	4-cell (47 WHr) or 3-cell (34 WHr) Lithium Ion
Ports	HDMI, Mini DisplayPort, RJ-45, Headphone/Microphone combo jack
Webcam	720p HD webcam
Security	Optional Fingerprint Reader, Smart Card reader, TPM 1.2
