22
Processor (Yonah) Intel
®
Centrino
®
Mobile Technology
Intel Yonah Dual Core Processor T2300 ~T2700
(1.66GHz~2.33GHz, 65nm, 667MHz, 2M L2)
Intel Yonah Single Core Processor T1300 ~ T1400
(1.66GHz~1.83GHz, 65nm, 667MHz, 2M L2)
Intel Celeron M processor 410~ 430
(Yonah 65nm, 533MHz, 1M L2)
Intel Merom Dual Core Processor (64bits)
(65nm, 667Mhz, 4M L2)
uFC-PGA Package 478 pins
533/667MHz FSB
BIOS 1M BB Flash ROM
Chipset (Calistoga) Intel 940GML/ 945GM/PM+ ICH7M
Main Memory Zero on board and two SO-DIMM memory sockets
256MB to maximum 2GB 533/667MHz DDR2
SDRAM
LCD Display 15.4" TFT-LCD WXGA, 1280x800, 16.7M col-
orsGlare type support
15.4" TFT-LCD WSXGA+, 1680x1050, 16.7M
colors
Graphics Intel 940GML/945GM Integrated graphics controller
Intel
®
Graphics Media Accelerator (GMA) 950
nVIDIA G72M/MV-128M(factory option)
CRT Display Modes VGA 640x480, 256/64K/16.7M colors
SVGA 800x600, 256/64K/16.7M colors
XGA 1024x768, 256/64K/16.7M colors
SXGA 1280x1024, 256/64K/16.7M colors
Hard Disk Drive One 2.5" 9.5mm IDE HDD 5400 rpm with SATA
150 support (PATA for option)
Supported capacities of 40/60/80/100 GB
Floppy Disk Drive N/A
Optical Disk Drive One ODD Bay type 5.25"/12.7mm optical storage
device(G-base), choices of
24/10/8/24X Combo CD-RW+DVD (factory option)
8/4/8X DVD+/-RW(factory option)
Modem and Bluetooth 56K Modem 1.5, V.90/92 support
Bluetooth: USB interface (Option)
PC Cards Slot Express card support
LAN & WLAN PCI-E Ethernet 10/100 or 10/100/1000 Base T on
board (factory option)
Support dual band antenna
Intel
®
PRO/Wireless 3945ABG, IEEE 802.11a+b+g
(PCI-E mini card interface) (Factory option)
Interface I/O Port 1 IEEE 1394
3 Audio jacks: Headphone-out(SPDIF Out), Mic-
In, Line-in
1 CRT/ DVI (factory option)
4 USB ports (v2.0)
1 S-Video out
1 RJ11 connector for Modem
1 RJ45 connector for Ethernet
1 Port Replicator Connector (factory option)
APPENDIX
Notebook Specifications
Audio Built-in High Definition Audio (2 channel)
Built-in two stereo speakers
Dual array Microphone
Card Reader Support Memory Stick(MS-Pro), Multi Media Card,
and Secure Digital(MS/MS PRO/MMC/SD)
Mini card One PCI-E Mini card
System Status Power on/Suspend, Battery Charging, Wireless
LED Button LAN, Caps Lock, Number Lock, HDD Access,
Media reader
6 quick start buttons: Power button, Internet, E-
mail, Mute, Silence mode, Wireless
Keyboard 86/87/90-key with Windows function keys
Hot Keys on Keyboard Function Keys
Fn+F1 Suspend switch
Fn+F2 Wireless Enable/Disable
Fn+F3 LCD/CRT/LCD+CRT Switch
Fn+F4 Brightness down
Fn+F5 Brightness up
Fn+F6 Mute
Fn+F7 Volume Down
Fn+F8 Volume Up
Fn+F9 Media Play/Pause
Fn+F10 Media Stop
Fn+F11 Media Play Backward
Fn+F12 Media Play Forward
Fn+ESC Blue tooth Enable/Disable
Fn+Home light sensor
Power Management Full feature ACPI power management, Stand-by,
Suspend to Disk, Suspend to RAM
ACPI 2.0 supported with Intel SpeedStep
Light sensor
Battery Pack & Life Li-Ion 6 cells,2200mAh/cell
Li-Ion 6 cells,2400mAh/cell
Li-Ion 9 cells,2400mAh/cell
Battery life up to 3 hrs (estimate)
AC adapter Output: 19V DC, 3.42A, 65W or 90W (for 945PM)
Input: 100~240V AC, 50/60Hz Universal
Pointing Device Built-in touch pad with 2-way scroll function
2 click buttons
Dimensions/Weight Dimensions: 355(W)x254.5(D)x25.5~35.2 (H)mm
Weight:~2.7Kg (with 15.4"W TFT LCD, Combo
Driver, 6-cells)
Security Kensington lock hole
OS & S/W Windows XP compliance
