Table 12. Audio and speaker specifications (continued)
Description Values
Controller
Realtek ALC3246
Stereo conversion
24-bit DAC (Digital-to-Analog) and ADC (Analog-to-Digital)
Internal interface
Intel HDA (high-definition audio)
External interface
● One Universal Audio Jack
● One Line-out re-tasking Line-in audio port
Speakers
Optional
Internal speaker amplifier
Integrated in ALC3246(Class-D 2 W)
External volume controls
Keyboard shortcut controls.
Speaker output average
2 W
Speaker output peak
2.5 W
Subwoofer output
Not supported
Microphone
Not supported
Storage
Your computer supports one of the following configurations:
● One 2.5-inch hard-disk drive
● One 3.5-inch hard-disk drive
● One M.2 2230 or 2280 solid-state drive (class 35 or class 40)
● One M.2 2230 or 2280 solid-state drive (class 35 or class 40) and one 3.5-inch hard-disk drive
● One M.2 2230 or 2280 solid-state drive (class 35 or class 40) and one 2.5-inch hard-disk drive
● One 2.5-inch hard-disk drive and one M.2 16 or 32 GB Intel Optane memory
● One 3.5-inch hard-disk drive and one M.2 16 or 32 GB Intel Optane memory
The primary drive of your computer varies with the storage configuration. For computers:
● with a M.2 solid-state drive, the M.2 solid-state drive is the primary drive
● without a M.2 drive, either the 3.5-inch hard-disk drive or one of the 2.5-inch hard-disk drives is the primary drive
Table 13. Storage specifications
Storage type Interface type Capacity
2.5 inch 5400 RPM, SATA hard-disk drive SATA Upto 2 TB
2.5 inch 7200 RPM, SATA hard-disk drive SATA Upto 1 TB
2.5 inch.7200 RPM, FIPS Self Encrypting Opal 2.0,
SATA hard-disk drive
SATA Upto 500 GB
3.5 inch 5400 RPM, SATA hard-disk drive SATA Upto 4 TB
3.5 inch 7200 RPM, SATA hard-disk drive SATA Upto 2 TB
M.2 2230 solid-state drive PCIe Gen 3 x4 NVMe, Class 35 Upto 512 GB
M.2 2280 solid-state drive PCIe Gen 3 x4 NVMe, Class 40 Upto 1 TB
Technical specifications 19
