Dell OptiPlex 7040 - Mini Tower - Removing the Optical Drive (3.5-Inch); Installing the Optical Drive (3.5-Inch); Installing the Optional SSD Card

Removing the optical drive (3.5-inch)
1. Follow the procedure in Before Working Inside Your Computer.
2. Remove the:
• cover
• bezel
3. To remove the optical drive:
a. Disconnect the data cable and power cable from the connectors on the optical drive [1, 2].
b. Press the blue release tab [3] and slide the optical drive out of the optical drive bay [4].
Installing the optical drive (3.5-inch)
1. Insert the optical drive into the optical drive bay until it clicks into place.
2. Connect the data cable and power cable to the connectors on the optical drive.
3. Install the:
• bezel
• cover
4. Follow the procedure in After Working Inside Your Computer.
Installing the optional SSD card
1. Remove the:
• cover
• bezel
2. Open the front bezel door.
3. Peel the adhesive tape (blue) from the rubber.
