Steps
1. Disconnect the speaker cable from the system board.
2. Press the release tab and lift the speaker along with the cable from the system board.
Installing the speaker
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following image indicates the location of the speaker and provides a visual representation of the installation procedure.
42
Disassembly and reassembly
