Dell OptiPlex 780 SFF - Small Form Factor Front;Back View

Front and Back View — Small Form Factor
1 optical drive 2 optical drive eject button
3 USB 2.0 connectors (2) 4 network connectivity light
5 diagnostic lights (4) 6 drive activity light
7 power button, power light 8 microphone connector
9 headphone connector 10 Media Card Reader (optional)
11 cover release latch 12 padlock ring
13 power connector 14 back panel connectors
15 expansion card slots (2)
1
2
4
6
78
3
910
5
15
12
11
1314
