Back Panel Connectors — Desktop, Mini-Tower, and Small Form Factor
Quick Setup
WARNING: Before you begin any of the procedures in this section, read the safety
information that shipped with your computer. For additional best practices information,
see www.dell.com/regulatory_compliance.
NOTE: Some devices may not be included if you did not order them.
1 parallel connector 2 serial connector
3 link integrity light 4 network connector
5 network activity light 6 line-out connector
7 line-in/microphone connector 8 USB 2.0 connectors (6)
9 VGA connector 10 eSata connector
11 DisplayPort connector
