Specifications 39
Connectors
External connectors:
Audio
back panel
two connectors for line-in/ microphone and
line-out
front panel
two front-panel connectors for headphones
and microphone
eSATA
one 7-pin connector
NOTE: The ultra small form factor computer
does not have an eSATA connector.
Network adapter
one RJ45 connector
Parallel
one 25-pin connector (bidirectional)
Serial
one 9-pin connector; 16550C-compatible
USB
front panel
two
back panel
six
NOTE: The ultra small form factor has five USB
connectors on the back panel.
NOTE: All the USB connectors are USB 2.0
compatible.
Video
mini tower, desktop, and small
form factor
15-hole VGA connector
20-pin DisplayPort connector
ultra small form factor
28-pin DVI-I connector
System board connectors:
PCI
mini tower and desktop
small form factor
two connectors
one connector
connector size
120 pins
connector data width
(maximum)
32 bits
