Dell P126G Service Manual

Table 1. Screw list (continued)
Component Secured to Screw type Quantity Screw image
Touchpad Palm-rest and keyboard
assembly
M2x2 2
I/O board Palm-rest and keyboard
assembly
M2x3 1
Display hinges Palm-rest and keyboard
assembly
M2.5x 5 5
Power-button board Palm-rest and keyboard
assembly
M2x3 2
Power-button bracket
(Only available in
configurations with a
fingerprint reader)
Palm-rest and keyboard
assembly
M2x3 2
Power-adapter port Palm-rest and keyboard
assembly
M2x3 1
USB Type-C bracket Palm-rest and keyboard
assembly
M2x3 2
System board Palm-rest and keyboard
assembly
M2x2 2
Major components of Inspiron 5400 2n1
The following image shows the major components of Inspiron 5400 2n1.
10
Removing and installing components
