Steps
Place the palm-rest and keyboard assembly on a clean and flat surface.
Next steps
1. Install the system board.
NOTE: The system board can be replaced with the heat sink and memory.
2. Install the display assembly.
3. Install the power button or power button with fingerprint reader.
4. Install the fan.
5. Install the speakers.
6. Install the I/O board.
7. Install the M.2 2230 solid-state drive or M.2 2280 solid-state drive, whichever applicable.
8. Install the wireless card.
9. Install the coin-cell battery.
10. Install the 3-cell battery (41 Wh) or the 4-cell battery (54 Wh), whichever applicable.
11. Install the base cover.
12. Follow the procedure in After working inside your computer.
56
Removing and installing components
