Table 19. Display specifications (continued)
Description Option one Option two Option three
Horizontal view angle
+/- 85 degrees +/- 85 degrees +/- 85 degrees
Vertical view angle
+/- 85 degrees +/- 85 degrees +/- 85 degrees
Pixel pitch
0.161 x 0.161 mm 0.161 x 0.161 mm 0.161 x 0.161 mm
Power consumption
(
maximum)
3.10 W 4.60 W 2.50 W
Anti-glare vs glossy finish
Anti-glare Anti-glare Anti-glare
Fingerprint reader (optional)
The following table lists the specifications of the optional fingerprint-reader of your Precision 3480.
Table 20. Fingerprint reader specifications
Description Values
Fingerprint-reader sensor technology
Capacitive
Fingerprint-reader sensor resolution
500 dpi
Fingerprint-reader sensor pixel size
108 x 88
Sensor
T
he following table lists the sensor of your Precision 3480.
Table 21. Sensor
Sensor support
Ambient Light Sensor
Accelerometer in the base: ST Micro LIS2DW12TR
Accelerometer in the hinge-up (Upsell config with Emza/ALS/IR camera): ST Micro LNG2DMTR
GPU—Integrated
T
he following table lists the specifications of the integrated Graphics Processing Unit (GPU) supported by your Precision 3480.
Table 22. GPU—Integrated
Controller Memory size Processor
Intel Iris Xe Graphics Dual-channel memory 13
t
h
Generation Intel Core i5/i7
Specifications of Precision 3480 23
