Table 38. Video port and resolution matrix (continued)
Port type USB Type-C Thunderbolt 4 with
D
isplayPort 1.4
HDMI 2.0 port
Maximum resolution—triple MST Three 4096 x 2304 at 60 Hz Not applicable
Storage
M.2 2230, 256 GB, PCIe NVMe Gen4 x4, Class 35 SSD
The following table lists the M.2 2230, 256 GB SSD specifications.
Table 39. 256 GB SSD specifications
Capacity 256 GB
Height (approximate) 3.5 mm (0.17 in.)
Width (approximate) 22.00 mm (0.87 in.)
Depth (approximate) 30.00 mm (1.18 in.)
Interface type PCIe Gen4
Speed (maximum) 64 Gb/s (up to 4 lanes)
MTTF 1.4M hours
Logical blocks 500,118,192
Power source
Power consumption (reference only)
● I
dle: 5 mW (PS4)
● Active: 4 W
Environmental operating conditions (non-condensing)
Temperature range 0°C to 70°C
Relative humidity range 10% to 90%
Op shock 1500G
Environmental non-operating conditions (non-condensing)
Temperature range -40°C to 70°C
Relative humidity range 5% to 95%
M.2 2230, 512 GB, PCIe NVMe Gen4 x4, Class 35 SSD
T
he following table lists the M.2 2230, 512 GB SSD specifications.
Table 40. 512 GB SSD specifications
Capacity 512 GB
Height (approximate) 3.5 mm (0.17 in.)
Width (approximate) 22.00 mm (0.87 in.)
Depth (approximate) 30.00 mm (1.18 in.)
Interface type PCIe Gen4
Speed (maximum) 64 Gb/s (up to 4 lanes)
Engineering specifications 37
