Dell P165G - Discrete GPU Specifications

Table 35. Intel Iris Xe Graphics specifications (continued)
Memory type Shared with system memory
Memory interface Not applicable (Unified Memory Architecture)
Estimated maximum power consumption (TDP) 15 W, included in the CPU power
Maximum color depth 10 bits
Maximum vertical refresh rate Up to 120 Hz
NOTE:
The refresh rate depends on the resolution.
External ports HDMI 2.0 port, DisplayPort over USB Type-C
Multiple display support Up to four displays including laptop display
Intel UHD Graphics
The following table lists the Intel UHD Graphics specifications.
Table 36. Intel UHD Graphics specifications
Bus type Integrated graphics
Memory type Shared with system memory
Graphics level i5/i7: GT2 (UHD)
Estimated maximum power consumption (TDP) 15 W
Overlay planes Yes
Operating systems graphics/video API support DirectX 12, OpenGL (4.5 from Intel CML POR)
Maximum vertical refresh rate
● H
DMI 2.0: 4096 x 2160 at 60 Hz, 24bpp (HDMI or optional
USB Type-C to HDMI dongle)
● Max Digital: 7680 x 4320 at 60 Hz, 24bpp (mDP or DP 1.4
over Type-C port)
External ports
● H
DMI 2.0 port
● DisplayPort over USB Type-C
Multiple display support
Up to four displays through DisplayPort Multi-Streaming
T
echnology (MST)
GPU—Discrete
N
VIDIA RTX A500, 4 GB, GDDR6
The following table lists the NVIDIA RTX A500 specifications.
Table 37. NVIDIA RTX A500 specifications
Feature Values
GPU QN20-E3 MQ
Cores CUDA cores 8192, Tensor cores 256, RT cores 64
Memory bandwidth 448 Gbps
Memory type GDDR6
Engineering specifications 35
