Next steps
1. Install the display assembly.
2. Install the thermal heat-sink.
3. Install the thermal fan.
4. Install the wireless card.
5. Install the M.2 2230 solid-state drive or the M.2 2280 solid-state drive, whichever applicable.
6. Install the battery.
7. Install the base cover.
8. Follow the procedure in After working inside your computer.
Display assembly
Removing the display assembly
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
About this task
NOTE: The display assembly removal procedure is the same for both clamshell and 2-in-1 convertible chassis.
The following images indicate the location of the display assembly and provide a visual representation of the removal procedure.
Removing and installing components
51
