About Your Monitor | 9
Back View
Back view with monitor stand
Label Description Use
1 VESA mounting holes
(100 mm x 100 mm -
behind attached VESA
Cover)
Wall mount monitor using VESA-compatible wall
mount kit (100 mm x 100 mm).
2 Regulatory label Lists the regulatory approvals.
3 Stand release button Releases stand from monitor.
4 Security lock slot Secures monitor with security lock (security lock
not included).
5 Barcode serial number
label
Refer to this label if you need to contact Dell for
technical support.
6 Dell Soundbar mounting
slots
Attaches the optional Dell Soundbar.
7 Cable management slot Use to organize cables by placing them through
the slot.
8 USB downstream port Connect your USB device. You can only use this
connector after you have connected the USB cable
to the computer and USB upstream connector on
the monitor.
