12 │ About your monitor
Bottom view
Bottom view without monitor stand
Label Description Use
1 Security lock slot Secures the monitor with security lock
(
security lock not included).
2 Power connector Connect the power cable (shipped with your
monit
or).
3 DisplayPort Connect your computer with the DisplayPort
cab
le (shipped with your monitor).
4 HDMI port Connect your computer with the HDMI cable.
5 Stand lock feature To lock the stand to the monitor using a M3 x
6
mm screw (screw not included).
6 DVI port Connect your computer with the DVI cable.
7 VGA connector Connect your computer with the VGA cable
(
shipped with your monitor, for Japan only).
8 USB 3.0 upstream port Connect the USB cable (shipped with your
m
onitor) to this port and your computer to
enable the USB ports on your monitor.
9 USB 2.0 downstream
port (2
)
Connect your USB device.
NOTE: T
o use this port, you must connect the
USB cable (shipped with your monitor) to the
USB-upstream port on the monitor and to
your computer.
