Dell P2424HEB - Resolution Specifications; Preset Display Modes

18 | About your monitor
Resolution specifications
Model P2424HEB
Horizontal scan range 30 kHz to 83 kHz
Vertical scan range 56 Hz to 76 Hz
Default resolution 1920 x 1080 at 60 Hz
Video display capabilities
(HDMI & DP & USB Type-C
alternate mode)
480p, 560p, 720p, 1080p
1080i (HDMI only)
Preset display modes
Display mode Horizontal
frequency
(kHz)
Vertical
frequency
(Hz)
Pixel clock
(MHz)
Sync polarity
(Horizontal/
Vertical)
VESA, 720 x 400 31.47 70 28.32 -/+
VESA, 640 x 480 31.47 60 25.17 -/-
VESA, 640 x 480 37.50 75 31.5 -/-
VESA, 800 x 600 37.88 60 40 +/+
VESA, 800 x 600 46.88 75 49.5 +/+
VESA, 1024 x 768 48.36 60 65 -/-
VESA, 1024 x 768 60.02 75 78.75 +/+
VESA, 1152 x 864 67.50 75 108 +/+
VESA, 1280 x 1024 64.0 60 108 +/+
VESA,1280 x 1024 80.0 75 135 +/+
VESA, 1600 x 900 55.99 60 118.25 +/+
VESA, 1920 x 1080 67.50 60 148.50 +/+
