About your monitor | 11
Bottom view
73 64 5 8 8
21
Label Description Use
1 Security lock slot Secures monitor with security cable lock (sold separately).
2 Power connector Connect the power cable (shipped with your monitor).
3 HDMI port Connect your computer with the HDMI cable (shipped
with your monitor, for Brazil only).
4 Stand lock Lock the stand to the monitor using a M3 x 6 mm screw
(screw not included).
5 DisplayPort Connect your computer with the DisplayPort cable
(shipped with your monitor).
6 VGA connector Connect your computer with VGA cable (shipped with
your monitor, for Japan only).
7 USB 3.0 upstream
port
Connect the USB cable (shipped with your monitor) from
this port to your computer to enable the USB ports on
your monitor.
8 SuperSpeed USB
5 Gbps (USB3.2
Gen 1) Type-A
downstream port
(4)
Connect your USB devices. *
NOTE: To use this port, you must connect the
USB upstream cable (shipped with your monitor)
between the monitor and the computer.
*To avoid signal interference, when a wireless USB device has been connected to a
USB downstream port, it is NOT recommended to connect any other USB devices to
the adjacent port(s).
