10 | About Your Monitor
Bottom View
21 3 4
11
56 7 98 10
Label Description Use
1 Security lock slot*
(based on Kensington
Security Slot
TM
)
Secures monitor with security cable lock
(sold separately).
2 AC power port To connect the monitor power cable.
3 HDMI port Connect your computer with HDMI cable (sold separately).
4 DP port (in) Connect your computer with DP cable.
5 USB-C port Connect to your computer using the USB-C cable.
The USB-C port offer the fastest transfer rate and
the alternate mode with DP 1.4 support the maximum
resolution of 3840 x 2160 at 60Hz PD 20V/4.5A,
15V/3A, 9V/3A, 5V/3A.
NOTE: USB-C is not supported on Windows versions
that are prior to Windows 10 for Billboard message
(Type-C to Type-A cable).
6&7
9&10
USB-A downstream
port (4)
Port with icon supports 5V/0.9A.
Connect your USB device. You can use these ports
only after you have connected the USB cable from the
computer to the monitor.
NOTE: To avoid signal interference, when a wireless
USB device has been connected to a USB downstream
port, it is NOT recommended to connect any other
USB devices to the adjacent port(s).
8 RJ-45 connector Connect Internet. You can surf Internet via RJ45 only
after you have connected the USB cable (A to C or C
to C) from the computer to the monitor.
11 Stand lock Lock the stand to the monitor using a M3 x 6 mm
screw (screw not included).
