Removing the display cable
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory
Compliance home page at
www.dell.com/regulatory_compliance.
Prerequisites
1 Remove the base cover.
2 Remove the battery.
3 Remove the display assembly.
4 Follow the procedure from step 1 to step 3 in “Removing the display
panel”.
5 Remove the camera.
Procedure
1 Peel off the tape and open the latch to disconnect the display cable from
the display panel.
2 Peel off the sensor-board cable tape and disconnect the sensor-board
cable.
3 Open the connector latch and disconnect the display cable.
4 Note the display cable routing and remove the display cable from the
routing guides on the display panel.
94
