REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
The components identified by in this manual have been
carefully factory-selected for each set in order to satisfy
regulations regarding X-ray radiation. Should replacement
be required, replace only with the value originally used.
The components identified by
shading and mark
!
are critical
for safety. Replace only with
part number specified.
P780
— 45 —
R730 1-216-421-11 METAL OXIDE 12 5% 1W F
R731 1-216-295-91 SHORT
R733 1-216-295-91 SHORT
R735 1-216-659-11 METAL CHIP 2.2K 0.50% 1/10W
R737 1-216-659-11 METAL CHIP 2.2K 0.50% 1/10W
R739 1-216-073-00 RES, CHIP 10K 5% 1/10W
R741 1-249-377-11 CARBON 0.47 5% 1/4W F
R743 1-249-377-11 CARBON 0.47 5% 1/4W F
R745 1-216-298-00 RES, CHIP 2.2 5% 1/10W
R747 1-216-298-00 RES, CHIP 2.2 5% 1/10W
R753 1-216-679-11 METAL CHIP 15K 0.50% 1/10W
R755 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R903 1-216-049-91 RES, CHIP 1K 5% 1/10W
R904 1-216-049-91 RES, CHIP 1K 5% 1/10W
R905 1-216-295-91 SHORT
R906 1-216-073-00 RES, CHIP 10K 5% 1/10W
R907 1-260-087-81 CARBON 100 5% 1/2W
R908 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R909 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R910 1-249-411-11 CARBON 330 5% 1/4W
R911 1-249-416-11 CARBON 820 5% 1/4W
R912 1-216-049-91 RES, CHIP 1K 5% 1/10W
R913 1-216-025-91 RES, CHIP 100 5% 1/10W
R914 1-216-025-91 RES, CHIP 100 5% 1/10W
R915 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R916 1-216-077-91 RES, CHIP 15K 5% 1/10W
R917 1-216-077-91 RES, CHIP 15K 5% 1/10W
R918 1-216-049-91 RES, CHIP 1K 5% 1/10W
R920 1-216-049-91 RES, CHIP 1K 5% 1/10W
R921 1-216-295-91 SHORT
R922 1-216-073-00 RES, CHIP 10K 5% 1/10W
R923 1-216-295-91 SHORT
R924 1-216-025-91 RES, CHIP 100 5% 1/10W
R925 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R927 1-216-295-91 SHORT
R929 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R931 1-216-659-11 METAL CHIP 2.2K 0.50% 1/10W
R932 1-216-077-91 RES, CHIP 15K 5% 1/10W
R933 1-249-417-11 CARBON 1K 5% 1/4W
R934 1-249-429-11 CARBON 10K 5% 1/4W
R935 1-216-025-91 RES, CHIP 100 5% 1/10W
R936 1-216-025-91 RES, CHIP 100 5% 1/10W
R937 1-216-025-91 RES, CHIP 100 5% 1/10W
R938 1-216-025-91 RES, CHIP 100 5% 1/10W
R940 1-216-661-11 METAL CHIP 2.7K 0.50% 1/10W
R943 1-249-413-11 CARBON 470 5% 1/4W
R944 1-216-043-91 RES, CHIP 560 5% 1/10W
R945 1-216-049-91 RES, CHIP 1K 5% 1/10W
R946 1-216-053-00 RES, CHIP 1.5K 5% 1/10W
R947 1-216-061-00 RES, CHIP 3.3K 5% 1/10W
R950 1-216-051-00 RES, CHIP 1.2K 5% 1/10W
R951 1-216-025-91 RES, CHIP 100 5% 1/10W
R957 1-216-017-91 RES, CHIP 47 5% 1/10W
R958 1-216-017-91 RES, CHIP 47 5% 1/10W
VARIABLE RESISTOR
RV501
!
1-241-767-21 RES, ADJ, CERMET 100K
RELAY
RY500 1-755-137-11 RELAY
RY601
!
1-755-067-21 RELAY
SWITCH
S602
!
1-771-757-11 SWITCH, PUSH (1 KEY)
S901 1-692-431-21 SWITCH, TACTILE
S903 1-692-431-21 SWITCH, TACTILE
S904 1-692-431-21 SWITCH, TACTILE
S905 1-692-431-21 SWITCH, TACTILE
S906 1-692-431-21 SWITCH, TACTILE
S908 1-692-431-21 SWITCH, TACTILE
SPARK GAP
SG501 1-519-422-11 GAP, SPARK
TRANSFORMER
T501
!
1-453-311-11 FBT ASSY NX-4404//X4L4
T503 1-433-979-11 TRANSFORMER, FERRITE (DFT)
T504 1-433-978-11 TRANSFORMER, FERRITE (HDT)
T505 1-431-413-11 TRANSFORMER, FERRITE (HST)
T601
!
1-433-847-14 TRANSFORMER, CONVERTER (SRT)
THERMISTOR
TH501 1-807-796-11 THERMISTOR
TH600
!
1-809-827-11 THERMISTOR, NTC
TH601 1-803-540-11 THERMISTOR
VARISTOR
VA601
!
1-801-073-31 VARISTOR TNR14V471K660
CRYSTAL
X901 1-767-641-11 VIBRATOR, CRYSTAL
X902 1-767-933-11 OSCILLATOR, CERAMIC
MISCELLANEOUS
!
1-419-255-12 COIL, DEGAUSSING
!
1-452-923-41 NECK ASSEMBLY (NA-2915)
!
1-453-311-11
FLYBACK TRANSFORMER ASSY, NX-4404//X4L4
!
1-783-795-11 CORD SET, POWER (JAPAN ONLY)
* 1-790-883-12 CABLE ASSY (15P DSUB)
3-704-372-01 HOLDER, HV CABLE
* 3-867-224-11 MANUAL, INSTRUCTION
* 3-867-225-11 MANUAL, CD-ROM
4-045-123-01 HOLDER, DEGAUSSING COIL
!
8-738-550-61 ITC ASSY, 17TKB-R1
[
D
