Dell P780 - 17" CRT Display User Manual

— 15 —
P780
REF.NO. PART NO. DESCRIPTION REMARK
Note: Note:
Les composants identifies per un trame et une marque
sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
The components identified by shading
and mark
are critical for safety. Replace
only with part number specified.
REF.NO. PART NO. DESCRIPTION REMARK
DIODE
D001 8-719-970-02 DIODE 1SR139-400T31
D002 8-719-911-19 DIODE 1SS119-25TD
D003 8-719-911-19 DIODE 1SS119-25TD
D004 8-719-911-19 DIODE 1SS119-25TD
D005 8-719-911-19 DIODE 1SS119-25TD
D007 8-719-109-89 DIODE HZS5.6NB2TD
D008 8-719-109-89 DIODE HZS5.6NB2TD
D014 8-719-911-19 DIODE 1SS119-25TD
D015 8-719-911-19 DIODE 1SS119-25TD
D104 8-719-970-83 DIODE HSS82-TJ
D105 8-719-970-83 DIODE HSS82-TJ
D106 8-719-970-83 DIODE HSS82-TJ
D111 8-719-062-51 DIODE 1PS226-115
D204 8-719-970-83 DIODE HSS82-TJ
D205 8-719-970-83 DIODE HSS82-TJ
D206 8-719-970-83 DIODE HSS82-TJ
D211 8-719-062-51 DIODE 1PS226-115
D304 8-719-970-83 DIODE HSS82-TJ
D305 8-719-970-83 DIODE HSS82-TJ
D306 8-719-970-83 DIODE HSS82-TJ
D311 8-719-062-51 DIODE 1PS226-115
FERRITE BEAD
FB001 1-412-911-11 FERRITE 0µH
FB004 1-412-911-11 FERRITE 0µH
FB005 1-412-911-11 FERRITE 0µH
FB006 1-412-911-11 FERRITE 0µH
FB009 1-412-911-11 FERRITE 0µH
FB010 1-412-911-11 FERRITE 0µH
FB011 1-412-911-11 FERRITE 0µH
FB012 1-412-911-11 FERRITE 0µH
FB102 1-216-295-11 SHORT
FB202 1-216-295-11 SHORT
FB302 1-216-295-11 SHORT
FILTER
FL002 1-412-911-11 FERRITE 0µH
IC
IC001 8-752-094-09 IC CXA2067AS
IC002 8-759-596-65 IC LM2415T
IC003 8-759-589-35 IC CXD9516P
IC004 8-749-016-27 IC H8D2957
IC005 8-759-100-96 IC NJM4558M-TE2
IC006 8-759-269-07 IC SN74HCT02ANSR
JACK
J001 1-251-598-11 SOCKET, CRT
CHIP CONDUCTOR
JR002 1-216-296-91 SHORT
JR005 1-216-296-91 SHORT
JR006 1-216-296-91 SHORT
JR007 1-216-296-91 SHORT
JR016 1-216-296-91 SHORT
JR017 1-216-296-91 SHORT
JR018 1-216-295-11 SHORT
JR019 1-216-296-91 SHORT
JR020 1-216-296-91 SHORT
JR021 1-216-296-91 SHORT
COIL
L002 1-412-911-11 FERRITE 0µH
L003 1-408-591-11 INDUCTOR 1µH
L005 1-412-529-11 INDUCTOR 22µH
L007 1-410-482-31 INDUCTOR 100µH
L009 1-216-295-11 SHORT
L010 1-412-911-11 FERRITE 0µH
L101 1-414-137-31 INDUCTOR 0.22µH
L102 1-412-052-21 INDUCTOR CHIP 1µH
L103 1-414-137-31 INDUCTOR 0.22µH
L201 1-414-137-31 INDUCTOR 0.22µH
L203 1-414-137-31 INDUCTOR 0.22µH
L301 1-414-137-31 INDUCTOR 0.22µH
L303 1-414-137-31 INDUCTOR 0.22µH
TRANSISTOR
Q001 8-729-046-80 TRANSISTOR 2SC4634LS-CB11
Q006 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
